Features

Newly redesigned, the Cub Cadet XT2 LX42 lawn tractor features a Kawasaki FR series twin cylinder engine and a Tuff Torq transmission. This stylish, redesigned dealer exclusive model features an AeroForce cutting deck that produces finer grass clippings and fewer clumps. A wide variety of attachments can be added for all-season function.

• 18HP/603cc Kawasaki FR Series Twin Cylinder Engine
• 42-inch, 3-blade fabricated deck
• Tuff Torq K46 Hydrostatic Transmission
• 3 gallon fuel capacity
• Ground speed: 5.5 mph forward/3 mph reverse
• Front wheels: 15 x 6 in - 6 in
• Rear wheels: 20 x 8 in - 8 in
• 3-year consumer warranty
• Model: 13AGA1TEA10

Model#: 17RIEACO010

Step up to the ultimate all-around mowing experience with the Ultima Series from Cub Cadet. The ZT2 50 zero-turn mower features a premium 23 HP/726cc Kawasaki twin-cylinder OHV engine that delivers commercial-grade power to meet your yard's toughest demands. The 50 in., heavy-duty AeroForce fabricated deck features a cutting system that delivers a signature cut, with fewer clumps and stragglers, finer clippings and increased evenness of cut. A muscular, 2 in. x 2 in. tubular steel frame holds up against the toughest obstacles. You'll ride in elite comfort with a 20 in. H back seat with a durable advanced polymer seat suspension, arm rests, adjustable lap bars with ergonomic hand grips, a rubber floor mat and ample leg room. An AGM battery provides reliable starting with a slower discharge so you won't have to worry about it going dead during the offseason. By adding our optimized bagging system, specifically designed to prevent clumping and blockage, you get even more from your mowing experience. Ideal for mowing slight rolling hills and several obstacles up to 4 acres. Backed by a strong 3-year/unlimited-hour warranty, limited lifetime warranty on frame and deck, and a nationwide network of Cub Cadet dealers for expert service and support, you'll get the ultimate mowing experience with the Cub Cadet Ultima Series.

Additional Resources

From the Manufacturer

• SDS
• Replacement Part List
• Troubleshooting Guide
• Instructions / Assembly
• Warranty
• Use and Care Manual
• Full Product Manual

• Specifications

  Dimensions: H 35 in, W 60 in, D 84 in

  Dimensions

  Assembled Depth (in.)	84 in	Assembled Height (in.)	35 in
  Assembled Width (in.)	60 in	Cutting Width (in.)	50 inches
  Front Wheel Size (in.)	13 in	Mower Deck Width (in.)	50 in
  Rear Wheel Size (in.)	20	Turning Radius (in.)	0

  Details

  Assembly Required	Yes	CA (CARB) Compliant	Not CARB Compliant
  Commercial / Residential	Residential	Cutting Options	Side-Discharge
  Deck Material	11 Gauge Steel	Deck Type	Fabricated
  Drive Type	Rear-wheel Drive	Engine Displacement (cc)	726
  Engine Make	Kawasaki Engine	Engine Torque (ft.-lb.)	0
  Fuel Tank Capacity (gallons)	3.5 gal	Horsepower (HP)	23 hp
  Included with Riding Mowers	Battery(s),Engine Oil	Lawn Mower Type	Zero Turn Mower
  Maximum Cutting Height (in.)	4.5 in	Maximum Forward Speed (mph)	7.5
  Maximum Reverse Speed (mph)	3.5	Minimum Cutting Height (in.)	1 in
  Mower Size	Large	Number of Blades	3
  Number of Blades	3 blades	Number of Cylinders	V-Twin
  Number of Deck Wheels	3	Oil Capacity (oz.)	64
  Power Type	Gas	Product Weight (lb.)	664 lb
  Recommended Oil Type	10W30	Refurbished	No
  Returnable	30-Day	Riding Mower Features	Adjustable Cutting Height, Adjustable Speed, Arm Rests, Assembly Required, Battery level indicator, Built-in Hitch, Cup Holder, Headlights, High Back, Hour Meter, Keyed start, Pneumatic Tires, Reverse Mowing, Swivel Wheels
  Size of Yard	2 - 4 Acres	Start Type	Electric
  Terrain Type	Flat with Obstacles, Hilly	Transmission Type	Hydrostatic

  Warranty / Certifications

  Certifications and Listings	No Certifications or Listings	Manufacturer Warranty	3-Year Limited Warranty
